Question statement

A square of side length {sidecm} cm has charges of different magnitudes placed at its four corners. Clockwise from the top right as viewed from above these are $q_1$ to $q_4$ , with values {q1}, {q2}, {q3} and {q4} nC. In this question, you are required to determine the total electric field, including both magnitude and direction, at the centre of the square due to this arrangement of point charges.

This question is a relatively complicated example of application of the principle of superposition.

You should use the values of the physical constants provided in the module notes, assume the medium is air, quote all answers to 4 significant figures and you may express values in scientific format.

Give any introductory information the student needs.

			Name	Type	Generated Value

Emag	decimal	dec("2.207365688499963238101326272508069854741e+4")
eps0	number	0.000000000008854
epsair	number	1.0005
Ex1	decimal	dec("8.39949430304296848680195848395454545455e+3")
Ex2	decimal	dec("-9.449431090923339693748645688363636363634e+3")
Ex3	decimal	dec("-3.149810363641113620840061613227272727274e+3")
Ex4	decimal	dec("-5.249683939401855333470512531254545454544e+3")
Extotal	decimal	dec("-9.449431090923340161257261348890909090902e+3")
Ey1	decimal	dec("8.39949430304296848680195848395454545455e+3")
Ey2	decimal	dec("9.449431090923339693748645688363636363634e+3")
Ey3	decimal	dec("-3.149810363641113620840061613227272727274e+3")
Ey4	decimal	dec("5.249683939401855333470512531254545454544e+3")
Eytotal	decimal	dec("1.994879896972704989318105509034545454545e+4")
k	number	8983250812.581928
q1	integer	-8
q2	integer	9
q3	integer	-3
q4	integer	-5
qq1	number	-0.000000008
qq2	number	9.000000000000001*10^(-9)
qq3	number	-3.0000000000000004*10^(-9)
qq4	number	-0.000000005
r	decimal	dec("7.778174593052023036818575966306688126535e-2")
rsq	decimal	dec("6.050000000000000417546860865949403817418e-3")
side	rational	11/100
sidecm	integer	11
theta	decimal	dec("1.965382405805330255479846784865504038131e+1")
thetad	decimal	dec("1.965382405805330255479846784865504038131e+1")
thetar	decimal	dec("3.43023940420703270228957933126075797451e-1")

Automatically regenerate variables?

Name

Data type

Value

xxxxxxxxxx

sqrt(Extotal^2+Eytotal^2)

JME function reference

Description

Magnitude of the field at the centre.

Describe what this variable represents, and list any assumptions made about its value.

Can an exam override the value of this variable?

Generated value: `decimal`

dec("2.207365688499963238101326272508069854741e+4")

← Depends on:

Extotal
Eytotal

→ Used by:

thetar

Parts

Field due to first charge Gap-fill
1. Gap Ex1 Number entry
  Add
2. Gap Ey1 Number entry
  Add
Field due to second charge Gap-fill
1. Gap Ex2 Number entry
  Add
2. Gap Ey2 Number entry
  Add
Field due to third charge Gap-fill
1. Gap Ex3 Number entry
  Add
2. Gap Ey3 Number entry
  Add
Field due to fourth charge Gap-fill
1. Gap Ex4 Number entry
  Add
2. Gap Ey4 Number entry
  Add
Total field Gap-fill
1. Gap Extotal Number entry
  Add
2. Gap Eytotal Number entry
  Add
Angle Gap-fill
1. Gap theta Number entry
  Add

Gap-fill

Ask the student a question, and give any hints about how they should answer this part.

Determine the electric field at the centre of the square due to $q_1$ ({q1}nC).

$E_x(q_1)=$ Ex1V/m

$E_y(q_1)=$ Ey1V/m

Advice

This is a problem of superposition of four different fields, which amounts to the sum of four vectors. Each field is an expression of Coulomb's Law, so that the pre-factor is

$\displaystyle {q_i\over 4\pi\varepsilon_0 r^2}$ ,

where since the point of interest is the centre of the square, the distance $r$ is the same for each point-charge (in this case {side*100}/ $\sqrt{2}\approx$ {siground(r*100,4)} cm). In each case the field points radially away from the point-charge so that for $q_1$ it is down and left in equal measures, for $q_2$ it is up and to the left, and so on. For negative charges the sign of $q$ can be thought of reversing the direction (fields converge on negative point charges). Take care in determining the direction and note that diagrams generally help!

The value of $E$ can be readily obtained and the direction in each case given by

$\displaystyle{1\over\sqrt{2}}\left(\pm \hat{i} \pm \hat{j}\right)$ ,

with the combinations of $\pm$ depending upon which charge we're considering and the $\sqrt{2}$ factor coming from the fact that this is a unit vector.

Once each vector field has been obtained they can be summed by component (apply the principle of superposition) giving the total $E$ -field at the centre of the square.

Finally the angle with the line joining $q_2$ and $q_4$ can be obained by noting that the dot product of the total field with the direction of the displacement from $q_2$ to $q_4$ yields an angle:

$\displaystyle{\vec{E}.\left(-\frac{\hat{i}}{\sqrt{2}}+\frac{\hat{j}}{\sqrt{2}}\right)=\left|\vec{E}\right|\cos(\theta)}$

$\displaystyle{-E_x+E_y=\sqrt{2}\left|\vec{E}\right|\cos(\theta)\Rightarrow \theta=\cos^{-1}\left(\frac{E_y-E_x}{\sqrt{2}\left|\vec{E}\right|}\right)}$ .

It then only remains to determine the value of theta that lies in the required angle range.
